Technical data:
Color of laser: Red or Green
Standard: 2 lines (1 vertical line, 1 horizontal line)
Accuracy: +-1.5mm / 5m
Laser module Safty level: class 2 (IEC/EN60825-1/2014)
waterproof / dustproof: IP54
Self-leveling time <= 3 s
Damping: magnetic
Laser Wavelength: 635nm
Working distance diameter: 40m (with receiver / detector)
Outdoor working: If the laser level is needed to be worked outdoor frequently, it is better to buy a green beam laser.
Tilt Slash function: Yes
Self-leveling: Yes
Auto adjustment range: ±4 degrees
working tempature: -10 degrees celsius to 50 degrees celsius
Power: DC3.0 (AA1.5 X2) (NOT INCLUDED IN THE PACKAGE)
Gross weight: 0.6 kg
Size: 17*15*11CM
Simple structure and Operation (Red beam laser):
(1). We locked the pendulum to protect it before we ship this laser level to you,
(2). Unlock the pendulum, press the POWER button at first time, it can transmite two lines. NOTE: The laser lines would twickle if the laser level is not put in level.
(3), Press POWER button second time, the vertical line would be off, the horizontal line is still on.
(4), Press POWER button third time, the horizontal line would be off, the vertical line is still on.
Laser receiver mode: When the pendulum is unlocked, it can work with laser receiver (detector).
Turn off the laser lines: Only when the pendulum is locked, press the POWER button and hold it for 3 seconds, the laser lines can be turned off.
Tilt slash line: When the pendulum is locked, it can make tilt slash lines, but the laser lines would twickle in every 5 seconds.
Simple structure and Operation (Green beam laser):
(1). We locked the pendulum to protect it before we ship this laser level to you.
(2). Unlock the pendulum, press the POWER button at first time, it can transmite two lines. NOTE: The laser lines would twickle if the laser level is not put in level.
Turn off the laser lines: Only when the pendulum is locked, press the POWER button, the laser lines can be turned off.
Tilt slash line: When the pendulum is locked, it can make tilt slash lines, but the laser lines would twickle in every 5 seconds.
ITEMS in the parcel that you will get:
Red 2 lines Laser level: 1 pc.
Magnetic bracket: 1 set.
Manual: 1 pc.
Cloth bag: 1 pc.
ITEMS in the parcel that you will get:
Green 2 lines Laser level: 1 pc.
Magnetic bracket: 1 set.
Manual: 1 pc.
Cloth bag: 1 pc.
